The Ubiquiti UniFi Pro XG 24 PoE is a professional-grade 1U rack-mount Layer 3 switch combining high-density PoE+++ delivery with 10 GbE access ports, 25G SFP28 uplinks, and Etherlighting™ — at a price point between the standard USW range and the full enterprise ECS family. All 24 data ports support PoE+++ (up to 90W per port) — enough to power the latest Wi-Fi 7 access points, PoE++ cameras, and high-power devices without compromise.
Sixteen 10 GbE RJ45 ports, eight 2.5 GbE RJ45 ports, and two 25G SFP28 uplinks deliver 460 Gbps switching capacity with 230 Gbps non-blocking throughput. An internal 870W PSU powers both the switch and the 720W PoE budget, with USP RPS DC backup input for added resilience. Layer 3 features include DHCP server, inter-VLAN routing, and static routing. NDAA compliant, CE/FCC/IC certified.
Key highlights
- 24 × PoE+++ ports — up to 90W per port for Wi-Fi 7 APs and high-power devices
- 16 × 10 GbE RJ45 + 8 × 2.5 GbE RJ45 + 2 × 25G SFP28 uplinks
- 460 Gbps switching capacity, 230 Gbps non-blocking throughput
- 720W total PoE budget from internal 870W PSU
- USP RPS DC backup input for power resilience
- Layer 3 — DHCP, inter-VLAN routing, and static routing
- Etherlighting™ on all Ethernet and SFP28 ports
- Pro AV profiles — Dante, NDI, Q-SYS, SDVoE, and more
- 1.3″ touchscreen LCM display for on-switch management
- NDAA compliant, CE/FCC/IC certified
Recommended for
- Professional offices & campuses — high-power PoE+++ distribution for Wi-Fi 7 APs and dense PoE deployments
- Pro AV environments — built-in Dante, NDI, and Q-SYS profiles for clean AV network setup alongside PoE-powered devices
- Data centres & server rooms — 10 GbE access ports and 25G SFP28 uplinks for high-throughput server and storage connections
- Mid-scale enterprise networks — professional-tier performance between the standard USW range and the full ECS enterprise family
</div
Performance
Switching performance
Switching capacity
| Switching capacity | 460 Gbps |
| Non-blocking throughput | 230 Gbps |
| Forwarding rate | 342 Mpps |
| Packet buffer size | 8 MB |
| Supported VLANs | 1,000 |
| MAC address table size | 128,000 |
Layer 3 table sizes
| ARP entries | 128,000 |
| IPv4 routes | 256,000 |
| IPv4 static routes | 512 |
| Access lists (IPv4) | 256 |
| Access lists (MAC) | 256 |
Port layout
| 2.5 GbE RJ45 (PoE+++) | 8 ports — 2.5G/1G/100M/10M |
| 10 GbE RJ45 (PoE+++) | 16 ports — 10G/5G/2.5G/1G/100M/10M |
| 25G SFP28 uplinks | 2 ports — 25G/10G/1G |
| Total PoE ports | 24 (all PoE+++) |
| Max PoE per port | PoE 15.4W / PoE+ 30W / PoE++ 60W / PoE+++ 90W |
| Total PoE budget | 720W |
Features
Layer 3 features
- DHCP server (local networks)
- DHCP relay
- Inter-VLAN routing
- Static routing (local networks)
Layer 2 features
- LACP port aggregation
- STP & RSTP
- QoS (DSCP)
- IGMP snooping
- Advanced IGMP configuration
- 802.1X control
- MAC-based ACLs & device isolation
- IP-based ACLs & network isolation
- DHCP snooping & guarding
- Egress rate limit
- Flow control
- Storm control
- Multicast & broadcast rate limiting
- MAC address blocking
- MAC-based port restriction
- Port isolation
- Port mirroring
- Jumbo frames
- LLDP-MED
- Voice VLAN
- Loop protection
- Virtual network override
Pro AV profiles
- Play
- Dante
- Q-SYS
- NDI
- SDVoE
- Shure
- AES67
- Crestron
Compliance
CE
FCC
IC
Anatel: 04322-25-08356
Hardware
Physical
| Dimensions | 442 × 480 × 44 mm (17.4 × 18.9 × 1.7″) |
| Form factor | 1U rack mount, full-depth |
| Weight (without brackets) | 7.9 kg (17.4 lb) |
| Weight (with brackets) | 8.0 kg (17.6 lb) |
| Enclosure | SGCC steel |
| Mount material | SGCC steel |
| Supported rack depth | 482.6 mm (19″) four-post racks, posts 600–1,066 mm |
| LCM display | 1.3″ touchscreen |
| Management | Ethernet, AR |
| Etherlighting™ | Ethernet ports + SFP28 uplinks |
| ESD protection | Air: ±30kV, Contact: ±20kV |
Power
| Power supply | Internal AC/DC 870W |
| Power input | 100–240V AC, 50/60 Hz (universal) |
| DC backup input | USP RPS compatible |
| Max power consumption (excl. PoE) | 150W |
| Max power consumption (incl. PoE) | 870W |
| Total PoE budget | 720W |
Environmental
| Operating temperature | -5 to 40°C (23 to 104°F) |
| Operating humidity | 10–90% non-condensing |
In the box
UniFi Pro XG 24 PoE switch with rack mount brackets and power cable. Internal 870W PSU included. USP RPS unit and SFP28 transceivers are sold separately.
Software
Managed by UniFi Network
The USW-Pro-XG-24-POE is fully managed through the UniFi Network application — the same centralised platform used across the entire UniFi ecosystem. Configure VLANs, PoE schedules, port profiles, inter-VLAN routing, and Layer 3 features from a single interface with no per-device licensing fees.
Core management capabilities
- Port management — configure speed, PoE output, VLAN assignment, and port profiles per port from the UniFi dashboard.
- PoE scheduling — set time-based PoE on/off schedules per port to manage power consumption and device uptime.
- Layer 3 routing — configure DHCP server, DHCP relay, inter-VLAN routing, and static routes directly in UniFi Network.
- VLAN configuration — create and manage VLANs and 802.1Q tagging across all ports.
- Remote monitoring — real-time port statistics, power draw per port, and switch health visible from anywhere via UniFi Cloud.
- Pro AV profiles — one-click network optimisation for Dante, NDI, Q-SYS, and other professional AV protocols.
- Firmware updates — push updates remotely without on-site access.
Requirements
| UniFi Network | Version 9.1.120 or later |
| Hosting | Self-hosted or UniFi Cloud |
| Licensing | None — free with no per-device fees |
Documentation
Downloads & resources
Download the Ubiquiti UniFi Pro XG 24 PoE installation guide covering rack mounting, port configuration, PoE setup, and first-time setup via UniFi Network.
